Brand:
AEROQUIP
Weight:
0.22 LBS
Mfr Part Number:
FJ5994-07-0806S
Angle shape:
90 Degree
Compatible hose ID IN:
0.380
Compatible hose ID MM:
9.652
Compatible hoses:
GH134
Compatible tube OD IN:
0.50
Compatible tube OD MM:
12.700
Construction Style:
Reusable
End size 1:
-8
End type 1:
Female ORFS swivel
Hex size 1 IN:
0.944
Hex size 1 MM:
24.000
Hex size 2 IN:
0.630
Hex size 2 MM:
16.002
Hose cut off factor IN:
1.100
Hose cut off factor MM:
28.000
Hose size:
-6
Inside diameter IN:
0.255
Inside diameter MM:
6.500
Product material:
Carbon steel
Tube OD 1 IN:
0.500
Tube OD 1 MM:
12.700
A dimension IN:
2.830
A dimension MM:
71.800
Thread size 1:
13/16-16 UN
Product length in:
3.300
Finish plating:
Zinc plating
Product height in:
1.890
Product height mm:
48.006
Product length mm:
83.820
Product width in:
0.940
Product width mm:
23.876
Drop dimension IN:
1.150
Drop dimension MM:
29.20
Compliances:
SAE J2064 Type E, Class 1
Seal material:
Hydrogenated Nitrile (HNBR)
