Brand:
J.W. SPEAKER
Weight:
2.56 LBS
Mfr Part Number:
0555091
Model:
8690 Adaptive 2
Shape:
Round
Outer Lens Material:
Polycarbonate
Outer Lens Color:
Clear
Housing Material:
Aluminum
Housing Color:
Grey
Min Operating Temp (F):
-40
Max Operating Temp (F):
65
Connector or Wiring:
H4
Mating Connector:
H4, AMP#172615-2
Raw Lumen Output:
3,520 (High Beam) | 2,120 (Low Beam)
Effective Lumen Output:
1,600 (High Beam) | 1,050 (Low Beam)
Candela Output:
60,000 (High Beam) | 8,300 (Low Beam)
Input Voltage:
12
Operating Voltage:
9-16
Current Draw 1:
1.9
NMFC:
17870
NMFC Sub Code:
8
HS Tariff:
8512.20.20.00
Country of Origin:
US
Wire Color 1:
Black
Wire Function 1:
Ground
Wire Color 2:
White
Wire Function 2:
High Beam
Wire Color 3:
Yellow
Wire Function 3:
Low Beam
Wire Color 4:
Red
Wire Function 4:
Front Position
Technology:
LED
Product Height (mm):
143
Product Width (mm):
143
Product Depth (mm):
82.5
Product Weight (lbs):
2.56
