Brand:
J.W. SPEAKER
Weight:
7.60 LBS
Mfr Part Number:
0556273
Model:
9900 LP
Shape:
Rectangular
Outer Lens Material:
Polycarbonate
Outer Lens Color:
Clear
Housing Material:
Aluminum
Housing Color:
Black
Min Operating Temp (F):
-30
Max Operating Temp (F):
55
Connector or Wiring:
6-Pin Delphi (#12052848)
Mating Connector:
Delphi (#12052848)
Raw Lumen Output:
4,300 (High Beam) | 2,370 (Low)
Effective Lumen Output:
1,060 (High Beam) | 587 (Low)
Candela Output:
58000
Input Voltage:
12-24
Operating Voltage:
9-30
Current Draw 1:
5
NMFC:
17870
NMFC Sub Code:
8
HS Tariff:
8512.20.20.00
Country of Origin:
US
Wire Color 1:
Red
Wire Function 1:
Front Position
Wire Color 2:
Black
Wire Function 2:
Ground
Wire Color 3:
White
Wire Function 3:
High Beam
Wire Color 4:
Yellow
Wire Function 4:
Low Beam
Wire Color 5:
Blue
Wire Function 5:
DRL
Technology:
LED
Product Height (mm):
334
Product Width (mm):
83
Product Depth (mm):
85
Product Weight (lbs):
4.3
