  • 111-6820 80 SERIES AUTO LOCK YOKE

111-6820 80 SERIES AUTO LOCK YOKE

WEASLER ENGINEERING

No reviews yet Write a Review
SKU:
WEA111-6820

Description:

CV WIDE ANGLE TRACTOR YOKE
Multiple Series Auto-lok Yoke

PTO drive shafts begin with a tractor yoke, it is the leading connection between the the tractor and the driveline. Weasler provides the CV wide angle tractor yokes with auto-lok or safety slide lock connections, and all connection types can be included on a 50° CV or 80° CV drive shaft or assembly. All yokes are compliant with, ANSI/ASABE AD5673, ANSI/ASABE S604 and EN1265. Agricultural CV wide angle tractor yokes are offered in 1 3/8" 6-spline (type 1), 1 3/8" 21-spline (type 2), and 1 3/4" 20-spline (type 3) options to fit the specific tractor connection needed.

111-6820 80 SERIES AUTO LOCK YOKE

Description:

CV WIDE ANGLE TRACTOR YOKE
Multiple Series Auto-lok Yoke

PTO drive shafts begin with a tractor yoke, it is the leading connection between the the tractor and the driveline. Weasler provides the CV wide angle tractor yokes with auto-lok or safety slide lock connections, and all connection types can be included on a 50° CV or 80° CV drive shaft or assembly. All yokes are compliant with, ANSI/ASABE AD5673, ANSI/ASABE S604 and EN1265. Agricultural CV wide angle tractor yokes are offered in 1 3/8" 6-spline (type 1), 1 3/8" 21-spline (type 2), and 1 3/4" 20-spline (type 3) options to fit the specific tractor connection needed.

$582.40
Brand:
WEASLER ENGINEERING
Weight:
7.85 LBS
Mfr Part Number:
111-6820
Bore 1:
1.75 inches
Bore 1 Value:
1 3/4-20 SPLINE
Connection 1:
AUTO-LOK
Product Height:
4.75 inches
HP@1000RPM:
232 HP
HP@540RPM:
151 HP
Product Length:
6.00 inches
Shipping Volume:
127.53 in3
Product Weight:
7.85 pounds
Product Width:
3.30 inches
