Brand:
TIMKEN
Weight:
12.80 LBS
Mfr Part Number:
HA590419
ABS Encoder / # Teeth:
(96)
ABS Type - Tone Ring / Sensor / Encoder (T/S/E):
E
ABS/Non-ABS (Y/N):
Y
Bearing Type:
TAPERED ROLLER
Bolt Circle Diameter B (in.):
5.000
Bolt Circle Diameter B (mm):
127.00
Bolt Circle Diameter H (in.):
4.962
Bolt Circle Diameter H (mm):
126.03
Bolt Quantity I:
(3)
Bolt Size I (in.):
M12 X 1.75
Brake Pilot Dia E (in.):
2.836
Brake Pilot Dia E (mm):
72.03
Driven - Non Driven (D / N):
D
Flange (#):
(2)
Flange Diameter A (in.):
6.487
Flange Diameter A (mm):
164.77
Flange Offset F (in.):
2.046
Flange Offset F (mm):
51.97
Flange Shape J:
TRIANGLE
Hub Pilot Dia G (in.):
4.014
Hub Pilot Dia G (mm):
101.96
Lug Bolts/Bolt Holes (#):
Y
Roll Form (Y):
Y
Spline Quantity:
(32)
Wheel Pilot Dia D (mm):
71.32
Wheel Stud Qty:
5
Wheel Stud Size (in.):
M14 X 1.5
