Brand:
BENDIX
Weight:
16.98 LBS
Mfr Part Number:
K042457
Maximum Operating Temperature:
176 °F (80 °C)
Minimum Operating Temperature:
-40 °F (-40 °C)
Cautionary Note(s):
All vent holes must be open
Stroke:
2.25 IN (57.2 MM)
Stud Thread Size:
M16 x 1.5-6g
Stud Spacing:
4.75 IN (120.7 MM)
Push Rod Thread / Style:
Spherical End
Mounting Stud Length:
1.72 IN (43.7 MM)
Chamber Type / Size:
T16/24
Service Chamber Joint Type:
Single Clamp Band
Push Rod Length [MM]:
15 mm
Port Angle:
270°
Clamp Angle:
90°
Service Chamber Vent Holes:
All Open
Chamber Style:
Double Diaphragm
Service Port (11):
3/8-18 NPTF
Parking Port (12):
3/8-18 NPTF
Parking Chamber Sealed:
No
| MACK: 745-K042457 | INTERNATIONAL: BXK042457 | UTILITY: BXK042457 | VOLVO: BW K042457 | FREIGHTLINER: BW K042457 |
| KENWORTH: K042457BXW | PACCAR: K042457BXW | PETERBILT: K042457BXW | TRUCKPRO: BWK042457 | HDATP GROUP MEMBER: K042457 |
| KEENE: K042457 | VIPAR GROUP MEMBER: K042457 |
