Brand:
BENDIX
Weight:
3.34 LBS
Mfr Part Number:
K070962
Country of origin (CO):
MX
Adapter Cable Included:
Not applicable to this part
Body Configuration:
2 SUP / 4 DEL (2H + 2V)
Cautionary Note(s):
Use caution when positioning solenoid connector.
Connector Type:
2-Way Circular DIN (ISO 15170-1 Twist-Lock)
Control Port:
1/4-18 NPT
Control Port Orientation (CW from Front Face):
90Adeg
Crack Pressure:
4.0 PSI
Delivery Port 1:
1/2-14 NPT
Delivery Port 2:
1/2-14 NPT
Delivery Port 3:
3/8-18 NPT
Delivery Port 4:
3/8-18 NPT
Delivery Port 5:
Not applicable to this part
Delivery Port 6:
Not applicable to this part
Delivery Port 7:
Not applicable to this part
Delivery Port 8:
Not applicable to this part
Exhaust Port:
Dust Shield
External Solenoid Supply Port:
Not applicable to this part
Internal Supply Passage to Cover:
Yes
Market Indicator:
Aftermarket New
Maximum Operating Temperature:
185 AdegF (85 AdegC)
Minimum Operating Temperature:
-40 AdegF (-40 AdegC)
Mounting:
M8 X 1.25-6g Stud (2x)
Mounting Bracket Direction:
Not applicable to this part
Mounting Bracket Location:
Bracket loose in box
Mounting Orientation (CW from Front Face):
Not applicable to this part
Supply Port 1:
1/2-14 NPT
Supply Port 2:
1/2-14 NPT
TMC Washer:
RV040
Voltage (Nominal):
12 Volts
