Description:
KN86020X EL850 Like Nu Compressor
Reman. EL850 4-Hole Base Mount
- Rotatable Head
- Belt Drive
- End Cap Oil Feed
- Base Oil Drain
- Overall Height: 11.00 in.
- Overall Width: 4.78 in.
- Overall Length: 10.08 in.
- External Shaft Length: 2.22 in.
- Approximate Weight: 24 lbs.
- Torque Nut to 80-100 ft. lbs.
Notes- Port orientation viewed from front.
- Changeover/Installation Instructions - L31043
- Service/Repair Instructions For Cylinder Head - L31059.
- Service Units are furnished without governors and manifolds and may require head rotation before installation or changeover.
- Thru-drive units must not exceed 65 ft. lbs. of transmitted torque.
- Include Installation Gaskets.
