Brand:
AEROQUIP
Weight:
0.06 LBS
Mfr Part Number:
03E-604
Angle shape:
Straight
Compatible hose ID IN:
0.250
Compatible hose ID MM:
6.400
Construction Style:
Crimp
End size 1:
-4
End type 1:
Female 37 degree swivel
Hex size 1 IN:
0.563
Hex size 1 MM:
14.288
Hex size 2 IN:
0.438
Hex size 2 MM:
11.112
Hose cut off factor IN:
1.070
Hose cut off factor MM:
27.000
Hose size:
-4
Inside diameter IN:
0.100
Inside diameter MM:
2.400
Product material:
Carbon steel
A dimension IN:
1.930
A dimension MM:
49.000
Thread size 1:
7/16-20 UNF
End connection torque:
11-12 lb-ft(15-16 Nm)
Finish plating:
Dura-Kote
Series:
E Series
