Brand:
AEROQUIP
Weight:
0.14 LBS
Mfr Part Number:
08E-106
Angle shape:
Straight
Compatible hose ID IN:
0.380
Compatible hose ID MM:
9.652
Compatible hoses:
H009 | H209 | H243 | H265 | H275 | H277 | H285 | H435 | H436 | SC-TW
Compatible tube OD IN:
0.37
Compatible tube OD MM:
9.398
Construction Style:
Crimp
End size 1:
-6
End type 1:
Male pipe (NPTF)
Hex size 1 IN:
0.750
Hex size 1 MM:
19.100
Hex size 2 IN:
0.750
Hex size 2 MM:
19.050
Hose cut off factor IN:
0.980
Hose cut off factor MM:
24.892
Hose size:
-6
Inside diameter IN:
0.390
Inside diameter MM:
9.906
Product material:
Carbon steel
Tube OD 1 IN:
0.370
Tube OD 1 MM:
9.398
A dimension IN:
2.642
A dimension MM:
51.300
Thread size 1:
3/8-18 NPTF
Product length in:
2.080
Finish plating:
Zinc plating
Series:
E Series
Product height in:
0.950
Product height mm:
24.130
Product length mm:
52.832
Product width in:
0.950
Product width mm:
24.130
