Eaton 14313-2 - ELocker Differential, 35 Spline, All Ratios for Jeep JL Wrangler Dana 44 (M220) Rear

No reviews yet Write a Review
SKU:
EDT14313-2

Description:

Eaton ELocker electronically controlled locking differential for the Dana 44 (M220) axle with 35-spline gears, all ratios. The stator must be removed for clearance before installing the ring gear, and reinstalled in this order: ring gear, stator assembly, bearing. Requires aftermarket 35-spline axle shafts (1.50 in. diameter, 24/48 DP spline, 30 degree pressure angle). Rubicon models will need an aftermarket locker control harness to integrate with the OEM locker control switch.

Eaton 14313-2 - ELocker Differential, 35 Spline, All Ratios for Jeep JL Wrangler Dana 44 (M220) Rear

Description:

Eaton ELocker electronically controlled locking differential for the Dana 44 (M220) axle with 35-spline gears, all ratios. The stator must be removed for clearance before installing the ring gear, and reinstalled in this order: ring gear, stator assembly, bearing. Requires aftermarket 35-spline axle shafts (1.50 in. diameter, 24/48 DP spline, 30 degree pressure angle). Rubicon models will need an aftermarket locker control harness to integrate with the OEM locker control switch.

$1,734.58
Brand:
EATON PERFORMANCE
Weight:
27.00 LBS
Mfr Part Number:
14313-2
Product Type:
Differential
Ring gear ratio:
All
Gear spline tooth count:
35 EA
Axle shaft diameter:
1.5 in
Ring gear size:
8.7 in
Differential type:
Locking
Vehicle usage:
Off-Road: Rock Crawl | Off-Road: Light Trail / Sand Sports | Off-Road: Work Truck / Towing | Off-Road: Extreme Off-Road | On Road: Work Truck / Towing
Catalog Notes:
The stator must be removed for clearance prior to installing the ring gear. Stator must be removed and reinstalled in the follow order: (1) Ring Gear, (2) Stator Assembly, (3) Bearing. Requires use of aftermarket 35 spline axle shafts. Axle DIA: 1.50
