Brand:
AEROQUIP
Weight:
0.80 LBS
Mfr Part Number:
190296-8S
Angle shape:
90 Degree
Compatible hose ID IN:
0.500
Compatible hose ID MM:
12.700
Construction Style:
Reusable
End size 1:
-8
End type 1:
Female 37 degree swivel
Hex size 2 MM:
15.000
Hose cut off factor IN:
1.610
Hose cut off factor MM:
40.894
Hose size:
-8
Inside diameter IN:
0.360
Inside diameter MM:
9.144
Product material:
Carbon steel
A dimension IN:
2.760
A dimension MM:
70.100
Thread size 1:
3/4-16 UNF
End connection torque:
38-42 lb-ft(52-58 Nm)
Product length in:
3.190
Finish plating:
Dura-Kote
Series:
100R5 Reusable
Product height in:
2.050
Product height mm:
52.070
Product length mm:
81.026
Product width in:
0.938
Product width mm:
23.813
Drop dimension IN:
1.090
Drop dimension MM:
27.69
Reusable socket hex IN:
0.938
Reusable socket hex MM:
23.000
