Brand:
AEROQUIP
Weight:
0.33 LBS
Mfr Part Number:
2048-4-8S
Angle shape:
90 Degree
End type 1:
Female pipe swivel (NPSM)
Hex size 1 IN:
0.690
Hex size 1 MM:
17.500
Hex size 2 IN:
1.060
Hex size 2 MM:
26.900
Product material:
Carbon steel
End type 2:
Female pipe (NPTF)
Thread sealant:
No
Finish plating:
Dura-Kote
Drop dimension IN:
1.300
Drop dimension MM:
33.00
Tube outside diameter 1 IN:
0.250
Tube outside diameter 1 MM:
6.4
Tube outside diameter 2 IN:
0.500
Tube outside diameter 2 MM:
12.7
Working temp max C:
204
Working temp max F:
400
Working temp min C:
-54
Working temp min F:
-65
