Brand:
AEROQUIP
Weight:
0.08 LBS
Mfr Part Number:
49X5
Angle shape:
90 Degree
End type 1:
Male pipe (NPTF)
Hex size 1 IN:
0.540
Hex size 1 MM:
13.700
Product material:
Brass
End type 2:
Male 37 degree
Item type:
Adapter-elbow
Thread sealant:
No
Drop dimension IN:
0.780
Drop dimension MM:
19.80
Tube outside diameter 1 IN:
0.220
Tube outside diameter 1 MM:
5.6
Tube outside diameter 2 IN:
0.220
Tube outside diameter 2 MM:
5.6
Working temp max C:
121
Working temp max F:
250
Working temp min C:
-54
Working temp min F:
-65
Thread size 27:
1/2-20 UNF
Working pressure bar:
138
Working pressure psi:
2000.00
