Brand:
AEROQUIP
Mfr Part Number:
4S16FLA16
Angle shape:
45 Degree
Compatible hose ID IN:
1.000
Construction Style:
Crimp
End size 1:
-16
End type 1:
Split flange code 61
Hose cut off factor IN:
3.590
Hose cut off factor MM:
91.300
Inside diameter IN:
0.760
Inside diameter MM:
19.200
Product material:
Carbon steel
A dimension IN:
5.160
A dimension MM:
131.000
Product length in:
6.070
Finish plating:
Zinc plating
Series:
4S/6S
Product height in:
3.170
Product height mm:
80.518
Product length mm:
154.178
Product width in:
2.084
Product width mm:
52.933
Drop dimension IN:
1.260
Drop dimension MM:
32.00
