Brand:
AEROQUIP
Weight:
1.55 LBS
Mfr Part Number:
5100-S1-20B
Angle shape:
Straight
Hex size 1 IN:
1.780
Hex size 1 MM:
45.212
Product material:
Brass
Application:
Bulk liquid transfer | Fluid transfer | Highway water lines | Hydraulics | Landfill and refuse
End type 2:
Male pipe (NPTF)
Item type:
Female half
End size 25:
-20
Seal material:
Nitrile (NBR)
Connection style:
Manual connect
Fluid compatibility:
Oil
Working temperature min F:
-40
Body size:
1 1/4"
Air inclusion max cc:
0.68
Flow rate GPM:
75.00
Fluid loss cc:
0.70000
Latch type:
Screw to connect
Valve type:
2 way
Working temperature max F:
250
Working temperature max C:
121
Working temperature min C:
-40
Working pressure max psi:
2750
Working pressure max bar:
190
Air inclusion max in3:
0.04
Flow rate lpm:
283.91
Fluid loss in3:
0.04300
