Brand:
AEROQUIP
Weight:
0.87 LBS
Mfr Part Number:
5650-8-10S
Angle shape:
Straight
End type 1:
Female Push to Connect
Hex size 1 IN:
1.060
Hex size 1 MM:
26.924
Product material:
Carbon steel
Application:
Agriculture | Construction | Fluid transfer | Snow plow/groomer
End type 2:
Female Pipe (NPT)
Item type:
Complete
Product length in:
3.890
Finish plating:
Zinc
Product length mm:
98.806
End size 25:
-8
Seal material:
Nitrile (NBR)
Connection style:
Manual connect
Certifications:
ISO 7241-1 Series A
Working temperature min F:
-40
Body size:
5/8
Air inclusion max cc:
2.80
Flow rate GPM:
12.00
Fluid loss cc:
2.80000
Latch type:
Push/pull
Valve type:
2 way
Working temperature max F:
250
Working temperature max C:
121
Working temperature min C:
-40
Working pressure max psi:
4000
Working pressure max bar:
276
Air inclusion max in3:
0.17
Flow rate lpm:
45.43
Fluid loss in3:
0.17100
Burst pressure min bar:
827
Burst pressure min psi:
12000
