Brand:
SPICER DRIVELINE
Weight:
4.65 LBS
Mfr Part Number:
70-53-61
Description:
Drive Shaft Midship Stub Shaft
Fits Tube Diameter:
3.500
Butt Diameter:
3.321
Spline End To Weld (K) In.:
5.050
Style:
2
Spline O.D.:
1.750
Spline End To Brg Shoulder (Y):
3.188
Bearing Diameter (C) In.:
1.771
Bearing Diameter (Max):
1.7717
Number of Splines Based On:
3.188
Number of Splines:
34 I
Shoulder Diameter (B) In.:
2.153
Spline Length (L) In.:
2.060
Involute:
Y
Shoulder Length (G) In.:
.322
Fits Tube Wall:
.095
For Use With:
End Yoke Or Companion Flange
Bearing Diameter (Min):
1.7712
Thread Size:
1.250-18
