Brand:
AEROQUIP
Weight:
1.31 LBS
Mfr Part Number:
75710E-Z91
Angle shape:
90 Degree
Compatible hose ID IN:
0.500
Compatible hose ID MM:
12.700
Compatible hoses:
H757
Compatible tube OD IN:
0.63
Compatible tube OD MM:
15.875
Construction Style:
Crimp
End size 1:
-10
End type 1:
Female ORB port ISO 11926-1
Hex size 1 IN:
1.063
Hex size 1 MM:
26.988
Hose cut off factor IN:
3.000
Hose cut off factor MM:
76.200
Hose size:
-10
Product material:
Carbon steel
Tube OD 1 IN:
0.625
Tube OD 1 MM:
15.875
A dimension IN:
4.250
A dimension MM:
107.950
Thread size 1:
7/8-14 UNF
Finish plating:
Dura-Kote
Series:
757 E
Drop dimension IN:
2.000
Drop dimension MM:
44.00
