Brand:
AEROQUIP
Weight:
1.00 LBS
Mfr Part Number:
8024
Color:
Stainless steel
Series:
Conv-O-Crimp
Compliances:
MIL-PRF-2104
Conductivity:
Non-conductive
Construction:
1 Ply braid
Cover material:
Stainless steel
Reinforcement material:
Stainless steel wire
Tube material:
PTFE
Abrasion resistance:
Premium
Bend radius min (inch):
4.500
Bend radius min (mm):
114.300
Burst pressure (bar):
207
Burst pressure (psi):
3000
Inside diameter (inch):
1.58
Inside diameter (mm):
40.13
Outside diameter (inch):
1.83
Outside diameter (mm):
46.48
Package form:
Bulk
Qualified hose fittings:
Conv-O-Crimp
Size:
-24
Vacuum rating (inHg):
10
Vacuum rating (mmHg):
254.00
Working pressure max (bar):
52
Working pressure max (psi):
750
Working temperature max (C):
204
Working temperature max (F):
400.0
Working temperature min (C):
-54
Working temperature min (F):
-65.0
Tube wall thickness (inch):
0.13
Tube wall thickness (mm):
3.17
