Brand:
AEROQUIP
Weight:
1.05 LBS
Mfr Part Number:
EH22717
Application:
Air
Color:
Red
Series:
EH227 Series
Product height in:
1.060
Product height mm:
26.900
Product width in:
1.060
Product width mm:
26.900
Compliances:
SAE J20 Class A
Proposition 65:
Cancer and Reproductive Harm
Conductivity:
Conductive
Construction:
4 Ply braid
Cover material:
Silicone
Reinforcement material:
Aramid (Kevlar)
Tube material:
Silicone
Abrasion resistance:
Standard
Burst pressure (bar):
21
Burst pressure (psi):
300
Inside diameter (inch):
1.06
Inside diameter (mm):
26.90
Outside diameter (inch):
1.38
Outside diameter (mm):
35.05
Package form:
Bulk
Qualified hose fittings:
Contact Danfoss for fittings
Size:
-17
Working pressure max (bar):
3
Working pressure max (psi):
40
Working temperature max (C):
260
Working temperature max (F):
500.0
Working temperature min (C):
-54
Working temperature min (F):
-65.0
Lay line style:
Ink jet
