Brand:
AEROQUIP
Weight:
5.12 LBS
Mfr Part Number:
EH22780
Application:
Air
Color:
Red
Series:
EH227 Series
Product height in:
5.000
Product height mm:
127.000
Product width in:
5.000
Product width mm:
127.000
Compliances:
SAE J20 Class A
Proposition 65:
Cancer and Reproductive Harm
Conductivity:
Conductive
Construction:
4 Ply braid
Cover material:
Silicone
Reinforcement material:
Aramid (Kevlar)
Tube material:
Silicone
Abrasion resistance:
Standard
Bend radius min (inch):
3.800
Bend radius min (mm):
96.520
Inside diameter (inch):
5.00
Inside diameter (mm):
127.00
Outside diameter (inch):
5.32
Outside diameter (mm):
135.10
Package form:
Bulk
Qualified hose fittings:
Contact Danfoss for fittings
Size:
-80
Working pressure max (bar):
3
Working pressure max (psi):
40
Working temperature max (C):
260
Working temperature max (F):
500.0
Working temperature min (C):
-54
Working temperature min (F):
-65.0
Lay line style:
Ink jet
