Brand:
AEROQUIP
Weight:
0.34 LBS
Mfr Part Number:
FD69-1012-08-08
Angle shape:
Straight
End size 1:
-8
End type 1:
Female Pipe (NPT)
Hex size 1 IN:
1.120
Hex size 1 MM:
28.448
Product material:
Carbon steel
Thread size 1:
1/2-14 NPT
Application:
Bridge/concrete repair | High pressure cleaning | Paint stripping | Shipyards
Item type:
Male half
Finish plating:
Zinc trivalent
Seal material:
Nitrile (NBR)
Connection style:
Manual connect
Fluid compatibility:
Gas | Oil | Water
Working temperature min F:
-4
Body size:
1/2
Flow rate GPM:
45.00
Latch type:
Push to connect
Valve type:
Straight thru
Working temperature max F:
212
Working temperature max C:
100
Working temperature min C:
-20
Safety locking mechanism:
Sleeve lock
Working pressure max psi:
10000
Working pressure max bar:
690
Burst pressure min bar:
2758
Burst pressure min psi:
40000
