Brand:
AEROQUIP
Weight:
0.09 LBS
Mfr Part Number:
FD90-1004-06-04
Angle shape:
Straight
End type 1:
Female ORB port ISO 11926-1
Hex size 1 IN:
0.690
Hex size 1 MM:
17.526
Product material:
Carbon steel
Application:
Agriculture | Chemical | Construction | Fluid transfer | Food and beverage | General industry | Hydraulics | Oil and gas | Transportation
Item type:
Male half
Product length in:
1.320
Finish plating:
Zinc trivalent
Product height in:
0.690
Product height mm:
15.700
Product length mm:
33.500
Product width in:
0.690
Product width mm:
15.700
Seal material:
Nitrile (NBR)
Connection style:
Automatic connect
Fluid compatibility:
Hydraulic fluid
Certifications:
SAE J1502 Interchange
Working temperature min F:
-40
Body size:
1/4
Air inclusion max cc:
0.02
Flow rate GPM:
0.60
Fluid loss cc:
0.10000
Latch type:
Push/pull
Valve type:
2 way
Working temperature max F:
250
Working temperature max C:
121
Working temperature min C:
-40
Safety locking mechanism:
Sleeve lock
Working pressure max psi:
7000
Working pressure max bar:
483
Burst pressure min bar:
1931
Burst pressure min psi:
28000
