Brand:
AEROQUIP
Weight:
0.14 LBS
Mfr Part Number:
FF3910-0606S
Angle shape:
90 Degree
Hex size 1 IN:
0.550
Hex size 1 MM:
14.0
Hex size 2 IN:
0.690
Hex size 2 MM:
17.5
Product material:
Carbon steel
Thread size 1:
9/16-18 UNF
End type 2:
Male 37 degree
Thread sealant:
No
Finish plating:
Dura-Kote
Drop dimension IN:
1.660
Drop dimension MM:
42.2
Tube outside diameter 1 IN:
0.300
Tube outside diameter 1 MM:
7.6
Tube outside diameter 2 IN:
0.300
Tube outside diameter 2 MM:
7.6
Working temp max C:
204
Working temp max F:
400
Working temp min C:
-54
Working temp min F:
-65
Thread size 27:
9/16-18 UNF
