Brand:
AEROQUIP
Weight:
1.00 LBS
Mfr Part Number:
FF90835-13
Application:
High temperature | Low pressure engine or coolant
Color:
Red
Series:
FF90835 Series
Compliances:
SAE J20
Proposition 65:
Cancer and Reproductive Harm
Conductivity:
Conductive
Cover material:
Silicone
Reinforcement material:
Aramid (Kevlar)
Tube material:
Silicone
Abrasion resistance:
Premium
Bend radius min (inch):
6.500
Bend radius min (mm):
165.100
Burst pressure (bar):
138
Burst pressure (psi):
2000
Inside diameter (inch):
2.50
Inside diameter (mm):
63.50
Outside diameter (inch):
2.63
Outside diameter (mm):
66.80
Size:
-13
Working pressure max (bar):
3
Working pressure max (psi):
40
Working temperature max (C):
260
Working temperature max (F):
500.0
Working temperature min (C):
-54
Working temperature min (F):
-65.0
Tube wall thickness (inch):
0.19
Tube wall thickness (mm):
4.83
Lay line style:
Ink jet
