Brand:
AEROQUIP
Weight:
0.28 LBS
Mfr Part Number:
FJ3514-1212S
Angle shape:
90 Degree
Compatible hose ID IN:
0.750
Construction Style:
Reusable
End size 1:
-12
End type 1:
Tube-O male long pilot
Hex size 1 IN:
1.377
Hex size 1 MM:
35.000
Hex size 2 IN:
1.377
Hex size 2 MM:
35.000
Hose cut off factor IN:
2.110
Hose cut off factor MM:
53.600
Inside diameter IN:
0.470
Inside diameter MM:
11.900
Product material:
Carbon steel
A dimension IN:
3.690
A dimension MM:
93.700
Thread size 1:
1 1/16-14 UN
Product length in:
4.380
Finish plating:
Zinc plating
Product height in:
4.280
Product height mm:
108.712
Product length mm:
111.252
Product width in:
1.380
Product width mm:
35.052
Drop dimension IN:
3.780
Drop dimension MM:
96.10
Seal material:
Hydrogenated Nitrile (HNBR)
