Brand:
AEROQUIP
Weight:
1.00 LBS
Mfr Part Number:
FJ5994-08-1216S
Angle shape:
90 Degree
Compatible hose ID IN:
1.000
Compatible hose ID MM:
25.400
Compatible hoses:
GH134
Compatible tube OD IN:
0.75
Compatible tube OD MM:
19.050
Construction Style:
Reusable
End size 1:
-14
End type 1:
Female ORFS swivel
Hex size 1 IN:
1.380
Hex size 1 MM:
35.100
Hex size 2 IN:
1.250
Hex size 2 MM:
31.800
Hose cut off factor IN:
1.780
Hose cut off factor MM:
45.212
Hose size:
-16
Inside diameter IN:
0.650
Inside diameter MM:
16.510
Product material:
Carbon steel
Tube OD 1 IN:
0.750
Tube OD 1 MM:
19.050
A dimension IN:
3.457
A dimension MM:
87.800
Thread size 1:
1 3/16-12 UN
End connection torque:
63-75 lb-ft(85-102 Nm)
Finish plating:
Dura-Kote
Drop dimension IN:
2.000
Drop dimension MM:
48.00
Compliances:
SAE J2064 Type E, Class 1
