Brand:
AEROQUIP
Weight:
0.13 LBS
Mfr Part Number:
GG306-NP05-04
Angle shape:
90 Degree
End type 1:
Male 37 degree
Hex size 1 IN:
0.550
Hex size 1 MM:
14.000
Hex size 2 IN:
0.750
Hex size 2 MM:
19.100
Product material:
Carbon steel
Thread size 1:
1/2-20 UNF
End type 2:
Male ORB BSPP
Item type:
Adapter-elbow
Thread sealant:
No
Finish plating:
Dura-Kote
Drop dimension IN:
1.240
Drop dimension MM:
31.50
Tube outside diameter 1 IN:
0.230
Tube outside diameter 1 MM:
5.8
Tube outside diameter 2 IN:
0.260
Tube outside diameter 2 MM:
6.6
Working temp max C:
204
Working temp max F:
400
Working temp min C:
-54
Working temp min F:
-65
Thread size 27:
G 1/4
