Brand:
AEROQUIP
Weight:
74.00 LBS
Mfr Part Number:
H036320BK-100
Application:
Petroleum transfer
Color:
Black
Series:
H0363 Series
Product height in:
1.250
Product height mm:
31.800
Product width in:
1.250
Product width mm:
31.800
Compliances:
MIL-L-2104
Conductivity:
Conductive
Construction:
2 Wire Braid
Cover material:
Nitrile (NBR)
Reinforcement material:
Brass plated steel wire
Tube material:
Nitrile (NBR)
Abrasion resistance:
Standard
Bend radius min (inch):
7.480
Bend radius min (mm):
190.000
Burst pressure (bar):
42
Burst pressure (psi):
600
Inside diameter (inch):
1.25
Inside diameter (mm):
31.80
Outside diameter (inch):
1.77
Outside diameter (mm):
44.96
Package form:
Reel
Qualified hose fittings:
1A/Z Series
Size:
-20
Vacuum rating (inHg):
28
Vacuum rating (mmHg):
711.20
Working pressure max (bar):
11
Working pressure max (psi):
150
Working temperature max (C):
82
Working temperature max (F):
180.0
Working temperature min (C):
-40
Working temperature min (F):
-40.0
Lay line style:
Ink transfer
Length (in):
1200.00000
Length (mm):
30480.00000
