Brand:
AEROQUIP
Weight:
0.20 LBS
Mfr Part Number:
S-10
Application:
Chemical transfer
Color:
Gray
Series:
S Series
Product height in:
0.500
Product height mm:
12.700
Product width in:
0.500
Product width mm:
12.700
Compliances:
MIL-PRF-7808
Construction:
2 Wire Braid
Reinforcement material:
Stainless steel wire
Tube material:
PTFE
Abrasion resistance:
Standard
Bend radius min (inch):
5.000
Bend radius min (mm):
127.000
Burst pressure (bar):
482
Burst pressure (psi):
7000
Impulse cycle (cycles):
150000
Inside diameter (inch):
0.50
Inside diameter (mm):
12.70
Outside diameter (inch):
0.68
Outside diameter (mm):
17.27
Package form:
Bulk
Qualified hose fittings:
Crimp fittings only
Size:
-10
Working pressure max (bar):
120
Working pressure max (psi):
1750
Working temperature max (C):
230
Working temperature max (F):
450.0
Working temperature min (C):
-54
Working temperature min (F):
-65.0
