Brand:
AEROQUIP
Weight:
27.98 LBS
Mfr Part Number:
WAL373391
Angle shape:
Elbow 90 degree
End size 1:
22L
End type 1:
24 deg. tube port light duty
Hex size 1 MM:
17.000
Hex size 2 MM:
22.000
Product material:
Carbon steel
Thread size 1:
M30x2
End type 2:
24 deg. tube port light duty
Item type:
Tube to tube connector
Finish plating:
Guardian Seal
End size 25:
22L
Tube outside diameter 1 MM:
22.0
Tube outside diameter 2 MM:
22.0
Thread size 27:
M30x2
Working pressure bar:
250
Hex size 3 MM:
22.0
Working temperature max C:
120
Working temperature min C:
-40
Complete connector:
Yes
Product serial name:
P-WV
Model Code 1:
P-WV 22 L A4GS
