Brand:
AEROQUIP
Weight:
18.56 LBS
Mfr Part Number:
WAL604514
Angle shape:
Straight
End size 1:
12L
End type 1:
24 deg. tube port light duty
Hex size 1 MM:
27.000
Product material:
Carbon steel
Thread size 1:
M18x1.5
End type 2:
Male ISO 9974-2 type E (L)
Item type:
Male stud connector
Product length in:
1.339
Finish plating:
Guardian Seal
Product height in:
1.063
Product height mm:
27.000
Product length mm:
34.000
Product width in:
1.063
Product width mm:
27.000
Seal material:
Nitrile (NBR)
Tube outside diameter 1 MM:
12.0
Tube outside diameter 2 MM:
12.0
Thread size 27:
M16x1.5
Working pressure bar:
400
Working temperature max C:
120
Working temperature min C:
-40
Complete connector:
No
Product serial name:
GES
M-WD
Model Code 1:
GES 12 L/M22X1,5-WD A4GS
