Brand:
AEROQUIP
Weight:
18.86 LBS
Mfr Part Number:
WAL605750
Angle shape:
Straight
End size 1:
12L
End type 1:
24 deg. DKO swivel light duty
Hex size 1 MM:
19.000
Hex size 2 MM:
22.000
Product material:
Carbon steel
Thread size 1:
M18x1.5
End type 2:
Female ISO 9974-1 port
Item type:
Gauge fitting
Product length in:
1.595
Finish plating:
Guardian Seal
Product height in:
0.866
Product height mm:
22.000
Product length mm:
40.500
Product width in:
0.866
Product width mm:
22.000
Seal material:
Nitrile (NBR)
Tube outside diameter 1 MM:
12.0
Tube outside diameter 2 MM:
12.0
Thread size 27:
M18x1.5
Working pressure bar:
400
Working temperature max C:
120
Working temperature min C:
-40
Complete connector:
No
Product serial name:
EMASD
Model Code 1:
EMASD 12 LR A4GS
