Brand:
AEROQUIP
Mfr Part Number:
1A12EK8
Angle shape:
Straight
Compatible hose ID IN:
0.500
Compatible hose ID MM:
12.700
Compatible tube OD IN:
0.75
Compatible tube OD MM:
19.050
Construction Style:
Crimp
End size 1:
-12
End type 1:
24 deg. tube port heavy duty
Hex size 1 IN:
1.060
Hex size 1 MM:
26.924
Hex size 2 MM:
27.000
Hose cut off factor IN:
1.110
Hose cut off factor MM:
28.300
Hose size:
-8
Inside diameter IN:
0.380
Inside diameter MM:
9.600
Product material:
Carbon steel
Tube OD 1 IN:
0.750
Tube OD 1 MM:
19.050
A dimension IN:
2.280
A dimension MM:
58.000
Thread size 1:
M24x1.5
End connection torque:
52-66 lb-ft(70-90 Nm)
Product length in:
2.280
Finish plating:
Dura-Kote
Series:
1A/Z Series
Product height in:
1.220
Product height mm:
30.988
Product length mm:
57.912
Product width in:
1.220
Product width mm:
30.988
