Monroe 65118 - 65 Series Gas Magnum Shock Absorber

Description:

The Monroe® Magnum® Front and Rear Suspension Shock Absorber for class 6-8 vehicles is the first gas-charged, large-bore shock designed for air spring and taper leaf suspensions. The nitrogen gas charge provides the fast response essential for today's heavy-duty truck suspension systems.

Built for severe use class 6-8 trucks, the Magnum covers both front and rear positions for Mack CH and CL, Hino, and Ford B-600/B-700 platforms with 10-stage valving and large-bore construction.

• FOR HARDWORKING COMMERCIAL VEHICLES: Designed to handle high mileage and severe use class 6-8 trucks and buses.
• CONSISTENT RIDE: All-weather fluid handles extreme temperatures; larger 2-3/8-in. reserve tube holds more fluid (most applications).
• EXCEPTIONAL HANDLING: 10-Stage valving tuned to each vehicle; larger 1-3/4-in. bore for efficient damping (most applications).
• STRONG AND DURABLE: Shouldered and bonded bushings protect from bushing walkout; arc welds up to 360° for durability.
• BUILT TO LAST: Robust hydraulic lock-out prevents over-extension of air bags and protects the seal assembly (most applications).
• LONGER SERVICE LIFE: PTFE-coated bearing and nitrocarburized piston rod for long-lasting durability (most applications).
• REDUCED NOISE, VIBRATION AND HARSHNESS: Exceptional control isolating NVH under most driving conditions.
• IMPROVES PERFORMANCE: Nitrogen gas-charge reduces aeration and shock fade.
• BUY WITH CONFIDENCE: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty.

Common Fits: Front suspension on 1989-2007 Mack CH and CL. Rear suspension on 1981-1989 Mack U, 1983-1994 Mack MH, 1985-1993 Mack RW, 2004-2007 Mack CHN and CHU, 1986-1990 Ford B-600 and B-700, and 1989-2004 Hino FD series.
