Gates 85470 - EFG6K Spiral Wire Hydraulic Hose SAE 100R15

No reviews yet Write a Review
SKU:
GAT85470

Description:

EFG6K Spiral Wire Hose - SAE 100R15

Recommended for extremely high pressure, high impulse applications such as hydrostatic transmissions. EFG6K is designed to meet or exceed all requirements of SAE 100R15 specifications and performance requirements of EN 856 4SP (-6, -8, -10 and -12), EN 856 4SH (-12, -16, and -20), and ISO 3862 Type R15 (-6, -8, -10, -12, -16, -24). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum-based fluids.

  • Temperature Range: -40 Deg F to +250 Deg F (-40 Deg C to +121 Deg C)
  • Meets Flame Resistance Acceptance Designation MSHA 2G
  • Recommended Couplings: GlobalSpiral Couplings, GlobalSpiral MAX Pressure Couplings, Stainless Steel S Couplings (-6 through -20)
Gates 85470 - EFG6K Spiral Wire Hydraulic Hose SAE 100R15

Description:

EFG6K Spiral Wire Hose - SAE 100R15

Recommended for extremely high pressure, high impulse applications such as hydrostatic transmissions. EFG6K is designed to meet or exceed all requirements of SAE 100R15 specifications and performance requirements of EN 856 4SP (-6, -8, -10 and -12), EN 856 4SH (-12, -16, and -20), and ISO 3862 Type R15 (-6, -8, -10, -12, -16, -24). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum-based fluids.

  • Temperature Range: -40 Deg F to +250 Deg F (-40 Deg C to +121 Deg C)
  • Meets Flame Resistance Acceptance Designation MSHA 2G
  • Recommended Couplings: GlobalSpiral Couplings, GlobalSpiral MAX Pressure Couplings, Stainless Steel S Couplings (-6 through -20)
$4,003.64
Brand:
GATES
Weight:
67.80 LBS
Mfr Part Number:
85470
Type:
Hydraulic Hose
Industrial Description:
20EFG6KX25FT
Product Type:
EFG6K Spiral Wire Hose - SAE 100R15
Outside Diameter:
1.97 (unece.unit.INH)
Burst Pressure:
24000
Coupling Recommendation:
GlobalSpiral, Stainless Steel S
Cover Color:
Black
Cover Material:
Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline
Cover Type:
Type A - Flame & Oil Resistant
Dash Size:
20
EN Standard:
856 4SH
Hose Material:
Nitrile - Type C
Inside Diameter:
1.25 (unece.unit.INH)
ISO Standard:
N/A
Length:
25 (unece.unit.FOT)
Maximum Working Pressure:
6000
Reinforcement Material:
Six Alternating Layers of Spiraled, High-Tensile Steel
SAE Standard:
100R15
Temperature Rating:
-40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C)
Hose Pressure Description:
Extremely High Pressure
Tube Description:
Black, Oil-Resistant, Synthetic Rubber
