Brand:
BENDIX
Weight:
9.99 LBS
Mfr Part Number:
K019662
Country of origin (CO):
MX
Balance / Primary Service Port:
1/8-27 NPT (with Cover)
Body Configuration:
1 SUP / 8 DEL (6H + 2V)
Cautionary Note(s):
Not applicable to this part
Control / Secondary Service Port:
1/4-18 NPT
Control Port Orientation (CW from Front Face):
90Adeg
Crack Pressure:
4.0 PSI
Delivery Port 1:
1/2-14 NPT
Delivery Port 2:
1/2-14 NPT
Delivery Port 3:
1/2-14 NPT
Delivery Port 4:
1/2-14 NPT
Delivery Port 5:
Cored Closed
Delivery Port 6:
Cored Closed
Delivery Port 7:
3/8-18 NPT
Delivery Port 8:
3/8-18 NPT
Exhaust Port:
Dust Shield
Internal Supply Passage to Cover:
Not applicable to this part
Market Indicator:
Aftermarket New
Maximum Operating Temperature:
200 AdegF (93 AdegC)
Minimum Operating Temperature:
-40 AdegF (-40 AdegC)
Mounting:
3/8-16 UNC-2B (3x)
Mounting Bracket Direction:
Not applicable to this part
Mounting Bracket Location:
Not applicable to this part
Mounting Orientation (CW from Front Face):
180Adeg
Supply Port 1:
1/2-14 NPT
Supply Port 2:
Not applicable to this part
TMC Washer:
RV040
