801097 3/8" QUICK EXHAUST VALVE QE3

TECTRAN

No reviews yet Write a Review
SKU:
TEC801097

Description:

Humphrey 3/8 pipe QE3 quick exhaust valve is versatile. Product redirects exhausting air to its high flow 3/8 pipe exhaust port by sensing pressure differential. May be used as a shuttle valve, or achieve excellent check or flow control function with addition of plug or orifice. Compact body has high flow capacity. Molded shuttle outperforms competitive sheet stock types.

801097 3/8" QUICK EXHAUST VALVE QE3

Description:

Humphrey 3/8 pipe QE3 quick exhaust valve is versatile. Product redirects exhausting air to its high flow 3/8 pipe exhaust port by sensing pressure differential. May be used as a shuttle valve, or achieve excellent check or flow control function with addition of plug or orifice. Compact body has high flow capacity. Molded shuttle outperforms competitive sheet stock types.

$87.02
Brand:
TECTRAN
Weight:
5.00 LBS
Mfr Part Number:
801097
Number of Ports:
3 ports
Number of Positions:
2 positions
Valve Function:
Quick Exhaust
Piping Type:
Inline, Direct Piping
Options Included:
Use as Shuttle Valve, Plug EXH port for use as Check Valve
Approx Size (in) HxWxD:
2.38 x 1.5 x 2.08
Media:
Air, Inert Gas
Type of Operation:
Pressure Differential
Flow Capacity (Cv):
2.58
Port Size:
3/8 NPT
Lubrication:
Not required
Pressure Range (psi):
2-150
Ambient Temperature Range (?F):
-25~180
Wetted Materials:
Zinc diecast, Buna N
Weight (oz):
5.0
Price:
24.15
Quantity:
1459
Available:
2023-08-17
Flow - SCFM @ 100 psig:
155
Flow - LPM @ 6.9 bar:
4389
ESEOD (orifice) - in (mm):
0.379 (9.63)
Flow Coefficient (Cv):
2.58
