Monroe 74025 - 70 Series Gas Magnum Shock Absorber

No reviews yet Write a Review
SKU:
MON74025MM

Description:

The Monroe® Magnum® Rear and Front Suspension Shock Absorber for transit buses delivers a firm, controlled ride for greater stability and increased driver and passenger comfort. Magnum transit bus shocks are designed to meet or exceed demanding OE manufacturer specifications.

A multi-position transit bus Magnum shock covering International F5070 series, Thomas School Bus, and Prevost coach platforms, backed by Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty.

  • For Hardworking Transit Buses: Designed to handle the demands of high mileage and severe use transit buses.
  • Consistent Ride: All-weather fluid with special additives handles extreme temperatures; larger 2-3/4-in. reserve tube holds more fluid (when required).
  • Exceptional Handling: 10-Stage valving tuned per vehicle; larger 1-3/4-in. bore allows valve fine-tuning by allowing more hydraulic fluid to dissipate heat for better control.
  • Strong and Durable: Shouldered and bonded bushing with sleeve prevents bushing walkout; arc welds up to 360° for durability.
  • Built to Last: Hydraulic lock-out prevents over-extension of air bags and protects the seal assembly (when required).
  • Longer Service Life: PTFE-coated bearing and nitrocarburized piston rod for durability and extended service life (most applications).
  • Reduced NVH: Exceptional control isolating impact-related noise, vibration, and harshness under most driving conditions.
  • Buy with Confidence: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty.

Common Fits: International F5070 and F5070-SF (1981-2001, front); Thomas School Bus (1988-2006, rear); Prevost X3 Coach (2007-2019, rear).

Installation Manual

Installation Manual
Safety Data Sheet

Safety Data Sheet
Safety Data Sheet 2

Safety Data Sheet 2
Monroe 74025 - 70 Series Gas Magnum Shock Absorber

Description:

The Monroe® Magnum® Rear and Front Suspension Shock Absorber for transit buses delivers a firm, controlled ride for greater stability and increased driver and passenger comfort. Magnum transit bus shocks are designed to meet or exceed demanding OE manufacturer specifications.

A multi-position transit bus Magnum shock covering International F5070 series, Thomas School Bus, and Prevost coach platforms, backed by Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty.

  • For Hardworking Transit Buses: Designed to handle the demands of high mileage and severe use transit buses.
  • Consistent Ride: All-weather fluid with special additives handles extreme temperatures; larger 2-3/4-in. reserve tube holds more fluid (when required).
  • Exceptional Handling: 10-Stage valving tuned per vehicle; larger 1-3/4-in. bore allows valve fine-tuning by allowing more hydraulic fluid to dissipate heat for better control.
  • Strong and Durable: Shouldered and bonded bushing with sleeve prevents bushing walkout; arc welds up to 360° for durability.
  • Built to Last: Hydraulic lock-out prevents over-extension of air bags and protects the seal assembly (when required).
  • Longer Service Life: PTFE-coated bearing and nitrocarburized piston rod for durability and extended service life (most applications).
  • Reduced NVH: Exceptional control isolating impact-related noise, vibration, and harshness under most driving conditions.
  • Buy with Confidence: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty.

Common Fits: International F5070 and F5070-SF (1981-2001, front); Thomas School Bus (1988-2006, rear); Prevost X3 Coach (2007-2019, rear).

Installation Manual

Installation Manual
Safety Data Sheet

Safety Data Sheet
Safety Data Sheet 2

Safety Data Sheet 2
$79.11
Brand:
MONROE
Weight:
10.07 LBS
Mfr Part Number:
74025
Country of origin (CO):
US
Color:
Black
Compressed Length:
15.62 (unece.unit.INH)
Cylinder Color:
Black
Cylinder Finish:
Painted
Dust Shield Included:
Yes
Dust Shield Material:
Metal
Extended Length:
24.52 (unece.unit.INH)
Finish:
Painted
Gas Charged:
No
Grade Type:
Premium
Hydraulic Lockout:
Yes
Includes Bump Stop:
No
Internal Rebound Bumper:
No
Lower Mount Code:
L4
Lower Mount Type:
Loop (Eyelet) Bushing
Mounting Hardware Included:
No
Shock Absorber Body End Measuring Point:
Center of Loop
Shock Absorber Rod End Measuring Point:
Center of Loop
Travel Length:
8.9 (unece.unit.INH)
Upper Mount Code:
L4
Adjustable Damping4:
No
Lower Mount Code48:
L4
Upper Mount Code74:
L4
Lower Mount Type49:
Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL
Shaft Diameter61:
18 MM
Upper Mount Type75:
Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL
